MAKE A MEME View Large Image AisladorG.JPG Aislador en guía Banda X X-band microwave circulator This is a device with three ports with flanges to attach to waveguides It has the property that microwave power input at one port only comes out the next port to clockwise ...
View Original:AisladorG.JPG (1600x1200)
Download: Original    Medium    Small Thumb
Courtesy of:commons.wikimedia.org More Like This
Keywords: AisladorG.JPG Aislador en guía Banda X X-band microwave circulator This is a device with three ports with flanges to attach to waveguides It has the property that microwave power input at one port only comes out the next port to clockwise The circular arrow on the label indicates the direction that power travels It is made with magnetized ferrite material In this example a matched load resistance is attached to the righthand port Therefore microwaves entering the bottom port labeled INPUT will come out the top port labeled OUTPUT but microwaves entering the top port will be absorbed in the load own 2004 Antonio Pedreira Waveguides Circulator circuits Ferrite cores
