Keywords: Diffential amplifier transimission charackteristic.svg en Transimission charackteristic of a diffential amplifier 2016-07-22 own Menner other versions Source <source lang octave > U_delta linspace -0 2 0 2 81 U_T 0 0258 I_ratio -1 tanh U_delta / 2 U_T U_lin -1 2 U_T 1 2 U_T I_lin 1 -1 plot U_delta I_ratio linewidth 2 hold on plot U_lin I_lin --r linewidth 2 hold off title Transfer Characteristic T 300 K fontsize 12 ylabel Ratio I_ out / I_ ABC fontsize 12 ; xlabel ΔV V_ in1 ˆ’ V_ in2 in Volt fontsize 12 ; set gca linewidth 2 fontsize 12 print diff_amp_plot svg </source> cc-zero Bipolar amplifier circuits |
