| Keywords: Dryden F-8 Research Aircraft Fleet 1973 in flight, DFBW and SCW DVIDS697267.jpg en F-8 Digital Fly-By-Wire left and F-8 Supercritical Wing in flight These two aircraft fundamentally changed the nature of aircraft design The F-8 DFBW pioneered digital flight controls and led to such computer-controlled airacrft as the F-117A X-29 and X-31 Airliners such as the Boeing 777 and Airbus A320 also use digital fly-by-wire systems The other aircraft is a highly modified F-8A fitted with a supercritical wing Dr Richard T Whitcomb of Langley Research Center originated the supercritical wing concept in the late 1960s Dr Whitcomb also developed the concept of the area rule in the early 1950s It singificantly reduced transonic drag The F-8 Digital Fly-By-Wire DFBW flight research project validated the principal concepts of all-electric flight control systems now used on nearly all modern high-performance aircraft and on military and civilian transports The first flight of the 13-year project was on May 25 1972 with research pilot Gary E Krier at the controls of a modified F-8C Crusader that served as the testbed for the fly-by-wire technologies The project was a joint effort between the NASA Flight Research Center Edwards California now the Dryden Flight Research Center and Langley Research Center It included a total of 211 flights The last flight was December 16 1985 with Dryden research pilot Ed Schneider at the controls The F-8 DFBW system was the forerunner of current fly-by-wire systems used in the space shuttles and on today's military and civil aircraft to make them safer more maneuverable and more efficient Electronic fly-by-wire systems replaced older hydraulic control systems freeing designers to design aircraft with reduced in-flight stability Fly-by-wire systems are safer because of their redundancies They are more maneuverable because computers can command more frequent adjustments than a human pilot can For airliners computerized control ensures a smoother ride than a human pilot alone can provide Digital-fly-by-wire is more efficient because it is lighter and takes up less space than the hydraulic systems it replaced This either reduces the fuel required to fly or increases the number of passengers or pounds of cargo the aircraft can carry Digital fly-by-wire is currently used in a variety of aircraft ranging from F/A-18 fighters to the Boeing 777 The DFBW research program is considered one of the most significant and most successful NASA aeronautical programs since the inception of the agency F-8 aircraft were built originally for the U S Navy by LTV Aerospace of Dallas Texas The aircraft had a wingspan of 35 feet 2 inches; was 54 feet 6 inches long; and was powered by a Pratt Whitney J57 turbojet engine The F-8 Supercritical Wing was a flight research project designed to test a new wing concept designed by Dr Richard Whitcomb chief of the Transonic Aerodynamics Branch Langley Research Center Hampton Virginia Compared to a conventional wing the supercritical wing SCW is flatter on the top and rounder on the bottom with a downward curve at the trailing edge The Supercritical Wing was designed to delay the formation of and reduce the shock wave over the wing just below and above the speed of sound transonic region of flight Delaying the shock wave at these speeds results in less drag Results of the NASA flight research at the Flight Research Center Edwards California later renamed the Dryden Flight Research Center demonstrated that aircraft using the supercritical wing concept would have increased cruising speed improved fuel efficiency and greater flight range than those using conventional wings As a result supercritical wings are now commonplace on virtually every modern subsonic commercial transport Results of the NASA project showed the SCW had increased the transonic efficiency of the F-8 as much as 15 percent and proved that passenger transports with supercritical wings versus conventional wings could save 78 million in 1974 dollars per year for a fleet of 280 200-passenger airliners The F-8 Supercritical Wing SCW project flew from 1970 to 1973 Dryden engineer John McTigue was the first SCW program manager and Tom McMurtry was the lead project pilot The first SCW flight took place on March 9 1971 The last flight of the Supercritical wing was on May 23 1973 with Ron Gerdes at the controls Original wingspan of the F-8 is 35 feet 2 inches while the wingspan with the supercritical wing was 43 feet 1 inch F-8 aircraft were powered by Pratt Whitney J57 turbojet engines The TF-8A Crusader was made available to the NASA Flight Research Center by the U S Navy F-8 jet aircraft were built originally by LTV Aerospace Dallas Texas Rockwell International's North American Aircraft Division received a 1 8 million contract to fabricate the supercritical wing which was delivered to NASA in December 1969 NASA Identifier NIX-EC73-3495 2009-09-23 Glenn Research Center https //www dvidshub net/image/697267 697267 2012-10-10 13 56 WASHINGTON DC US PD-USGov Langley Research Center Images from DoD uploaded by Fæ | ||||
