| Keywords: EU-SE-Stockholm-Skarholmen-Distribution board.JPG en Distribution board in Stockholm apartment block Let's have a look some lacks 1 Executive diagram is missing Where from should I know which circuit breaker protects it Maybe 250A or even 800A but it's said nowhere 2 Probably one RCD Jordfelsbrytare protects all the groups again nowhere said If it is so - some small leak to the ground yellow-green wire and all apartment will stay in full darkness 3 All groups are protected by C10 circuit breakers 3 1 if you turn on some small load while your washing machine working in this line - circuit breaker will trip without any reason; 3 2 as there other fuse boxes are missing C is not suitable characteristic to circuit breakers for using in the living area; 3 3 chandeliers and other light fixtures could have more thin cable than 1 00mm² of copper so 10A circuit breaker might be too big to protect those weak knots 4 Electricity meter is somewhere outside of distribution board so energy company can cheat their consumers easily Remind - to do this works officially in Sweden you should have lot of useless papers or work in someone's company which has heap of those papers Even academic degree is required to strip the wire and clamp it in terminal Marasmus under the higher category My rate to this work done by qualified laymans which followed minimal requirements only to be correct Correct way B13 to outlets each group B4 to lighting each group C1 or C0 5 to modem and TV amplifier each group but access there is sealed so lacks couldn't be corrected at all own Dmitry G 2009-07-27 Distribution boards Load switches for DIN rail Circuit breakers for DIN rail RF amplifiers | ||||
