MAKE A MEME View Large Image Solec Kujawski longwave antenna feeder.jpg Picture of antenna feeder line from longwave radio transmitter in Solec Kujawski Poland The aerial mast of the station which broadcasts at 225 kHz with a radiated power of 1200 kilowatts is visible ...
View Original:Solec Kujawski longwave antenna feeder.jpg (2048x1536)
Download: Original    Medium    Small Thumb
Courtesy of:commons.wikimedia.org More Like This
Keywords: Solec Kujawski longwave antenna feeder.jpg Picture of antenna feeder line from longwave radio transmitter in Solec Kujawski Poland The aerial mast of the station which broadcasts at 225 kHz with a radiated power of 1200 kilowatts is visible in the background This type of transmission line is called a cage line and is used for high power low frequency transmission lines It functions similarly to a large coaxial cable The inner bundle of wires and the outer ring of wires carry equal magnitude and opposite phase RF currents to the antenna The outer ring of wires is connected to ground and serves as a shield own 2006-06-30 Przemysław Frasunek User Venglin Public domain 53 1 8 18 N 18 15 29 85 E region PL Solec Kujawski radio transmitter Cage lines
